Mogami W2933 - SELL BY Ft. 12 pair EZ/ID Multipair Analog Snake Bulk Cable, Black

Mogami W2933 - SELL BY Ft. 12 pair EZ/ID Multipair Analog Snake Bulk Cable, Black



List Price: $5.79
PAS DEAL $5.29
You save $0.50!
You'll earn 5 points
.


Availability: YES, in stock
Product Code : W2933-PERFT
QTY:

Description


JBL PRX412M - 12" 2-way Stage Monitor


Mogami W2933 SOLD PER FT - 12pair EZ/ID Multipair Analog Snake Bulk Cable, Black


CABLE CORE SPECIFICATIONS
Conductor 30/0.08A (0.15mm²) #26AWG (30×#40AWG)
Insulation 1.0Ø XLPE (Cross Linked Polyethylene) (0.039")
Drain Wire 7/0.18TA (0.18mm²) #25AWG (7×#33AWG)
Served Shield Approx. 58/0.10A Served (spiral) Shield
Jacket (Covering) 2.8Ø Flexible PVC (0.110")
Identification See core number identification table
mogami cable w293xd
Figure (1)


ELECTRICAL & MECHANICAL CHARACTERISTICS

DC Resistance at 20°C Inner Pair Conductor 0.13W/m(0.040W/Ft)
Shield 0.031W/m(0.0095W/Ft)
Capacitance at 1kHz, 20°C (Partial Capacitance Value) See Figure (1) K0 130pF/m(40pF/Ft)
K1 12pF/m(3.7pF/Ft)
Inductance 0.6µH/m(0.18µH/Ft)
Electrostatic Noise (Hum Pick-up)* 2.5mV Max.
Electromagnetic Noise at 10kHz*
(Inductance of the toroidal core: 595µH)
0.1mV Max.
Microphonics*
Method: Stepping on cable
50mV Max. at 50kW Load
Voltage Breakdown Must withstand at DC 500V/15sec.
Insulation Resistance at DC 125V, 20°C 100000 MW × m Minimum
Tensile Strength of one pair (26°C, 65% RH) 274N
Emigration Non-emigrant to ABS resin
Applicable Temperature -20°C‾ +70°C(-4°F‾ +158°F)
Standard UL13 CL2X 60#176;C / UL 20002 AWM 30V 60°C VW-1
* Using standard testing methods of Mogami Wire & Cable Corp.
