Inputs:
XLR connectors, electronically balanced
Impedance: bal. ca. 20 kΩ, unbal. ca. 10 kΩ
Max. Input Level: +32,5 dBu
Outputs:
Monitor/Line Outputs: XLR connectors, electronically balanced
Frequency Range: 4 Hz to 480 kHz ( -3 dB)
CMR: -82 dBu (at 1 kHz, 0dBu input level and unity gain)
Crosstalk at 1 kHz: -106 dB
THD&N at 1 kHz: 0,00085 % (at 0dBu input level and unity gain)
Noise: Unweighted -101,87 dB; A-weighted -104,76 dB; CCIR: -96,1 dB
Dynamic Range: 134,37 dB
Headphone Output:
6.3-mm TRS connector
Pin wiring: Tip = Left, Ring = Right, Sleeve = GND
Impedance: 0,18 Ω
Attenuation Factor: 180 @ 40Ohm
Frequency Range: 4 Hz to 480 kHz ( -3 dB)
CMR: -106 dBu (at 1 kHz, 0dBu input level and unity gain)
Crosstalk at 1 kHz: -106 dB
THD&N at 1 kHz: 0,00091 % (at 0dBu input level and unity gain)
Noise: Unweighted -101,12 dBu; A-weighted - 103,98 dBu; CCIR -95,02 dBuDynamic Range: 133,62 dB
Power Amplifier
Max. Output Power:
65m W (+20 dBm) at 1 kHz and 600 Ω connected impedance
560 mW (+20 dBm) at 1 kHz and 40 Ω connected impedance
Power Supply:
Voltages: 230 V AC, 50 Hz / 120 V AC, 60 Hz
Power Consumption: max 23,7 VA
Fuses: 100-120 V AC: T 1 A / 200-240 V AC: T 630 mA
Measurement & Weight:
Height x Width x Depth: 99 x 277 x 305 mm / 3.9 x 10.9 x 12 in
Weight: 4,3 kg / 9.5 lbs
0 dBu = 0,775 V. Specifications subject to change without notice.
